Important Notice: VVDI Mini Key Tool About Global Version Explanation.

From different regions customer's feedback, they also need some other regions remote options (like ME region they also need some SE and EU database options) So from 2.3.5 firmware there is GL version(Global) for customers.
1. GL version from old 3 regions include(EU ME SE US), those 3 old regions will automatically change to GL version from 2.3.5 firmware.
2. GL version will cover more remote options, will keep updating and adding more remotes.
(If you find any options missing compare to old region version, you can contact us, we will update)
3. GL version already released more universal smart key generation options
4. If customer still prefer to keep old region version, just send us your device SN, we will setting back for you.(GL or keep old region version,contact us from
Xhorse APP online service or PM Xhorse support)

XHORSE XKB501EN VVDI Key Tool Volkswagen B5Style Special Remote Key 3 Buttons

XHORSE VVDI2 for Volkswagen B5 Type Universal Remote Key 3 Buttons comes with quality guarantee for all have passed quality control before delivery. And it is compatible with all the VVDI tools including VVDI2 Mini Remote Programmer, VVDI Key Tool etc.). By using Xhorse Remote Key, you can accumulate member points which can be used to exchange VVDI 2 part special functions and accessories.

Xhorse VVDI mini key tool comes as the replacement of VVDI key tool. It features size, weight, high speed and compatibility of mobiles. Works well for chip cloning and remote key copying and generation. VVDI mini key tool is Multi-Language Now, it's free to switch language.

Xhorse Mini Key Tool Highlights:

1.Frequency test speed (super fast, frequnecy: 300-450Mhz, distance: 30 cm)
2.Database powerful,support more cars
3.Based on Mobile phone App via Bluetooth,very convenient, Both IOS and Android
4. Fast reading speed to get chip information
5. Get ID48 96bit authorization after you do 10 pcs xhorse remotes
6. Update Frequently
7. Compatible with large amont of xhorse universal remote keys

Xhorse App Language: English Chinese Spanish French Hindi Hebrew Italian Thai Polish Portuguese Korean and Indonesian

How to Change VVDI Mini Key Tool Language:
How to Change VVDI Mini Key Tool Language
About GL version explaination
From different regions customer's feedback, they also need some other regions remote options(like ME region they also need some SE and EU database options)

So from 2.3.5 firmware there is GL version(Global) for customers
1. GL version from old 3 regions include(EU ME SE), those 3 old regions will automatically change to GL version from 2.3.5 firmware.
2. GL version will cover more remote options, will keep updating and adding more remotes
（if you find any options missing compare to old region version,you can contact us , we will update）
3. GL version already released more universal smart key generation options
4. If customer still prefer to keep old region version, just send us your device SN, we will setting back for you.
(GL or keep old region version,contact us from Xhorse APP online service or PM Xhorse support)

VVDI Mini Key Tool Function Introduction:

Main Functions:

Remote Clone
Remote Generation
Garage Remote Generation
Transponder Clone
Generate Transponder
Frequency Test
Remote Renew
IC/ID Clone
Special Functions

It has ability to clone ID4C/4D, 46, 48, ID70, ID72 and can adapt to future updates.

It can also generate remotes for various car brands by connecting the mini key tool with the VVDI Mobile App available on both Android & iOS mobiles.

vvdi-mini-key-tool-function-1
vvdi-mini-key-tool-function-2
Transponder cloning:
Supports 46 42 4D 4E 11 33 8C 83 etc transponder cloning

Transponder Generating:
Support TP transponder & parts of special transponder
more than 700 vehicle models, reduce the stock of transponders efficiently.

Remote Cloning:
Support the HCS/Fixed code cloning, support non-HCS rolling code cloning, support PT22XX, LX918, HT6P20, VD5026, AX5326, HT12X fixed code editing.

Remote Generate:
Support 128 brands, over 2000 vehicle models. Generate

more abundant and thorough key pictures, transponder types, key blanks and remote matching data.
vvdi-mini-key-tool-transponder-and-remote-1

Frequency Test:
Support the power test within the range of 300-450Mhz.

Garage Remote Generating:
Support more than 100 types
vvdi-mini-key-tool-test-frequency
Toyota H Transponder:
Activate Toyota H transponder generation function

ID48 96 bit Transponder Online Calculation:
vvdi-mini-key-tool-48-96bit
Set type of vvdi super chip
Set type of vvdi super chip
Special Functions:
Remote Renew
Ignition switch coil signal detection
Unlock Toyota smart key
VVDI smart key clone
VVDI super transponder
Honda cycle key renew
ID/IC clone
vvdi-mini-key-tool-special-functions

Identifiable Transponders:
mini-key-tool-1
mini-key-tool-2
mini-key-tool-3
Mini KeyTool ID48 Cloning Tip:
"To effectively use the ID48 clone service, there are new policies in place that customers must follow. These include:
1. Setting up an Xhorse phone number account
2. Binding the device (Keytool, Mini Keytool, Keytool Max, or Keytool Max Pro) to the customer's Xhorse account
3. Logging in to the customer's Xhorse account on the Xhorse app and using that account, which must be the one that the device is bound to, for the ID48 clone service.
Note: Customers will not be able to use the ID48 clone service if their Xhorse account is not the one that is bound to the device."

VVDI Mini Key Tool Full Authorization (already activated):

AI - Car Remote Type
AI - Key Blade Type
AI - PIN Code
Remote - Vehicle Remote
Remote - Garage Remote
Remote -Proximity Remote
Generate Transponder - 7935/46/4D/48/8C
Generate Transponder - Toyota H (8A)
Transponder Clone - ID48 (96 bits)
Transponder Clone - ID46
Transponder Clone - ID4D
Transponder Clone - ID4E
Transponder Clone - ID70/ 83
Transponder Clone - ID11/ 12/ 13/ 4C/ 8C
Transponder Clone - Toyota/ Daihatsu G
Transponder Clone - Toyota H (8A)
Transponder Clone - ID33/42
Transponder Edit - 11/12/13/4C
Transponder Edit - 46/47/48/4D/4E
Remote Clone - Fix Code
Remote Clone - Rolling Code
Remote Clone - Make New
Detect Remote Frequency
Set Type of VVDI Super Transponder
VVDI Special TP
Special 4D to 4C
Unlock Toyota Smart Key
ID63 to ID83
Hyundai/Kia PIN Code
Copy BYD Smart Key
Detect Ignition Coil Signal
Online Technical Support
Technical Center
Video Center
History

How to Update Xhorse VVDI Mini Key Tool Firmware?

1.Connect Xhorse MINI KeyTool with computer via USB cable.

2.Start xhorse update kit software, and choose VVDI Lark, click find device.

3.After find device, click upgrade.

4.Finish.

5.Update xhorse app VVDI MINI Key Tool database.

Start VVDI MINI Key Tool, connect with xhorse app via bluetooth.
Update Xhorse VVDI Mini Key Tool Firmware 1

How to Combine Mini Key Tool with Xhorse App?
If fails to calculate ID48 96bit online and asks to bind device with Xhorse App, please combine mini key tool with Xhorse app to your account as image shows:
Login Xhorse APP, connect device by Bluetooth, go to "Device Information" and "Combine device".

How to Combine Mini Key Tool with Xhorse App

Mini Keytool Parameters:
LCD Size: 2.4’
LCD resolution: 320*240
Extra Power: 5V/1A
Usage Time: ≥10 Hour
Product Size: 108x194x28mm
Weight: 229g
Charge Current: 1A
Battery Capacity: 150mAh
Power: 600mW
Battery Voltage: 3.6-4.2V
